The effective volume of the tank is 36 cubic meters; the type of transport vehicle: FL; the item number of dangerous chemicals: 3. The overall dimensions of the insulated outer tank (length × width × height) (mm): 10500 × 2490 × 2060. The side protection material: aluminum alloy, connection method: bolt connection; the rear protection material: carbon steel, connection method: bolt connection, the rear protection section size/ground clearance (mm): 120 × 60/480. The suspension type is air suspension. The tractor is suitable for towing a semi-trailer for the transport of dangerous goods. Different types of fenders, tank top manhole boxes and guardrail structures can be selected, the front ladder can be cancelled, and the rear ladder can be selected; large notice board, trough hose box, tail side unloading box are optional. No rear heating device and no pipe box structure are optional. Rear tool box, frame cover, black skin structure are optional.
（Product Parameters）：
Standard Dimensions: 10500mm*2500mm*3800mm
Material: Carbon Steel
Axles: 3 axles, each rated at 13/16 tons, Customizable
Tank Capacity: 45 CBM, Customizable
Tank Thickness: 5mm
End Plate Thickness: 6mm
Baffle Thickness: 4mm
Compartments: 1 to 9, Customizable
Manhole: Anti-Explosion
Lift Axle: Available
Vehicle Examination: X-RAY Room Examination
Tank Shape: D Style/Round Style
Suspension: Mechanical suspension/Air suspension
