The aluminum tank body is in the shape of a square round tank, and the head is an expanded head, which makes the performance more stable and fully meets the national standards. Transport medium: See the description in the table above.
Frame part: The axle is a Fuwa 12-ton axle, drum brake, 12 12R22.5 tubeless ires, front and rear axles with ABS, automatic adjustment arms, 28-ton linkage legs (shake one side of the handle to lift both sides), 90# traction pin, 1 tool box, 1 spare tire rack, and other accessories are made according to the requirements of the announcement standard.
Aluminum alloy tank semi-trailer configuration:
The tank body is made of national standard high-quality aluminum alloy plate, the actual capacity of the tank body is about 40 cubic meters, and the thickness is strictly made according to the national standard GB18564-1 (tank body 6MM, head 7MM, partition 5MM), the number of partitions is designed, the tank top has double enclosures, and both sides are equipped with aluminum alloy movable guardrails. There are two European standard tank ports on the top of the tank, a DN100 master control valve with a rear bumper emergency cut-off switch at the bottom of the tank, and the water flows left and right at the rear of the tank through a three-way pipe. The two sides of the tank are stainless steel barrel tubes, and reflective strips, reflective tapes and labels are posted according to the announcement. There is a ladder and a safety notice board at the front of the tank.
The above is the standard configuration of the product. You can choose whether to separate the warehouse, tires, axles, steel rims and other brands or models according to the standard configuration, or you can bring your own standard accessories according to the conditions. Our company will use flexible mechanisms and sincere attitudes to consider everything for customers and meet your needs.
The specification
Standard Dimensions: 11200mm*2500mm*3800mm
Material: aluminum
Axles: 3 axles, each rated at 13/16 tons, Customizable
Tank Capacity: 40 CBM, Customizable
Tank Thickness: 5mm
End Plate Thickness: 6mm
Baffle Thickness: 4mm
Compartments: 1 to 9, Customizable
Manhole: Anti-Explosion
Lift Axle: Available
Vehicle Examination: X-RAY Room Examination
Tank Shape: D Style/Round Style
Suspension: Mechanical suspension/Air suspension
（Application and After-Sales Service）:
Our factory
Starway are committed to the design and manufacture of tank vehicles.We have a strong design team with nearly 40 years of design experience, which can not only design and manufacture products, but also provide professional technical services and solutions for customers’ transportation projects.
1: Our company promise a one-year warranty period, during this period, under normal use if there is damage to the accessories, we will provide our customers with free new accessories.
2: Operational problems, technical configuration issues, etc., We will promptly provide feasible solutions for our customers. We are investing in the construction of a number of foreign service department, will be better to serve the global customers.
3: We are serious about after-sales service.
Please contact us ,WhatsApp :+8618364783601 , Email : sales@starwayvehicle.com
