3 Axles45ft Dry cargo box Semi Trailer for sale
Starway vehicle Box type semi-trailers are generally used for transporting express delivery goods, refrigerated goods, or goods with high waterproof requirements. According to the appearance of semi-trailers, they can be divided into three categories:
(1) Drawbar type semi-trailer: docked with the tractor through a hard drawbar that can be connected and removed. If this type of semi-trailer is modified, it can be changed from a semi-trailer to a full trailer, similar to the material supply vehicle used in factories.
(2) Mid axle semi-trailer: This type is relatively rare, where the axle of the semi-trailer is placed in the middle position of the vehicle body to achieve flexible transportation by reducing the load-bearing capacity of the tractor.
(3) Ordinary semi-trailer: The same type as the grille semi-trailer is used, but the difference lies in the type of body. Box semi-trailers use a closed box body with side doors on both sides of the body. Flying wing type vehicles can fully open the body, while ordinary box type vehicles cannot open the body.
Product Parameters:
Dimension :13500x2600x3995mm
Inner Size:13300X2400X2300,
environmentally friendly natural resin glue
Paint: Powder spraying and coating
Color:Per customer’s requirement
Axle:BPW/Fuwa/Starway/ 13 ton x 3
Tire: Triangle 12R22.5/11.00R20 + one spare tyre
Rim:900*22.5 *13
Suspension:Mechanical suspension or air suspension(brand optional)
Leaf spring:Leaf spring 10pcs*90*13mm or air bag
Landing gear:JOST or other brand two-speed, landing gear 28T
Electrical System:24V 7-way socket; front marker lamp: white; side marker lamp: white & red; rear lamp: red; turning signal lamp: amber; wiring: electric cable protected by PVC conduit on main frame
Braking System :Dual line pneumatic brake, SAE hose and connector,with WABCO ABS
A
Features
The box is made of high-strength, stainless steel plates specially designed for container loading, with a reasonable structure and the advantages of large loading space, strong overload capacity, and light self weight;
The box type large box structure has good sealing performance for transporting goods, and the goods do not scatter. The design of large columns and sloping roof reduces wind resistance and improves fuel economy;
Adopting a series steel plate spring balanced suspension, it has high driving stability and a longer service life of the vehicle
The entire vehicle components are all from top domestic brands, with higher reliability and safety
Application and after-sale services:
Starway vehicle company promise two-year warranty period, during this period, under normal use if there is damage, we will provide free new spare parts
Main beam : 2 year
Suspension : one year
Axles /Axle bearing : one year
Breaking system : one year
Landing gear /Kingpin:one year
Tyre : 6 month
