3 Axles100 ton side dump semi trailer for sale
Starway 3 axles side dump trailer has a hydraulic system that lifts the cargo box so it can tilt to either side of the trailer. Side dump trailers do not need to deflate their air suspension before unloading, which provides very efficient unloading. Side dump trailers are commonly used for storage of cargo that requires the assistance of a loader, fine materials, semi-liquids, road construction, and excavation and tunnel mining.
Specifications
Dimensions: 13,000mm * 2,500mm * 3,800mm (Standard Dimensions, Customizable)
Payload:100 tons-150 ton
Main beam : Up20/Middle 1mm/Down 20mm
Axles: 3 axles *25 T, Customizable
Dump Style: Rear Dump, Customizable to Side Dump
Cylinder: HYVA (model depends on container length)
Main Beam Material: Q345/T700
Tires: 11.00R20/12R22.5/1200R20 * 8/12/16 pieces
Suspension: Mechanical or Air Suspension
Leaf Springs: 90mm*16mm*10 pieces
Landing Gear: 28T, Two-speed, JOST
King Pin: #50(2″)/#90(3.5″), JOST/other brands
Additional Customizable Options: Paint process, ABS, Reflective Tape, LED lights, etc.
